The graph shows the speed of a can travelling along a conveyor belt in a factory. The can's displacement (in metres) can be calculated from the area under this graph. What is it?

Question

The graph shows the speed of a can travelling along a conveyor belt in a factory. The can's displacement (in metres) can be calculated from the area under this graph. What is it?

BlackTom AI · Accepted Answer

When a velocity–time graph is integrated, the area under the curve represents displacement. In this graph, the can’s velocity is constant over a certain time interval, forming a rectangle. The base of the rectangle corresponds to the time interval, and the height corresponds to the velocity. Calculating the area of the rectangle: base × height = 5 × 2 = 10. Therefore, the displacement is 10 metres. Explanation for the options (even though no options are shown here): if the velocity were different or if the interval had a different width, the product would change accordingly. The key idea is that area under a velocity-time graph equals displacement, and for a constant velocity over a fixed duration, displacement is simply velocity multiplied by time.

MUF0121 Physics Unit 1 - Semester 2, 2025 2.10 Graphical analysis of motion

The graph shows the speed of a can travelling along a conveyor belt in a factory. The can's displacement (in metres) can be calculated from the area under this graph. What is it?

View Explanation

Log in for full answers

Similar Questions

The speed-time graphs for three vehicles X, Y, and Z are shown. If x, y, and z are the distance travelled by X, Y, and Z respectively in 8 s, which of the following comparison is correct?

What is the unit used to measure the quantity represented by the area under this graph?

The graph shows the speed of a remote controlled toy speed boat on a river. It speeds up for six seconds and then slows down for the same amount of time. The boat's displacement (in metres) can be calculated from the area under this graph. What is it?

The graph shows the speed of a remote controlled toy car on a pathway. It speeds up for one and a half seconds and then slows down for the same amount of time. The car's displacement (in metres) can be calculated from the area under this graph. What is it? Give your answer to 3 significant figures.

An object's movement is depicted by the following motion graph. [NOT DRAWN TO SCALE]The particle travels a distance of 251.1 m during the motion Find the maximum velocity, v, of the particle given the following values.A : 5.1 sB : 17.2 sC : 26.5 s

Which line is decelerating? If you cannot view this image, click here.

Using the following position vs. time graph, determine the total distance traveled between points B and D. d = _ _ _ _ _ _ c m
