Step 2: Shear and Moment Functions

A free-body diagram of a beam segment of length x is shown. The intensity of the triangular load at the section is found by proportion, that is,
w/x=(2kN/m)/(3m)
or
𝑤
=
(
2
3

𝑥
)

kN
/
m
. The resultant of the distributed loading is found from the area under the diagram. Thus,

\sum F_y=0=(3\,kN)-\frac{1}{2}\left(\frac{2}{3}x\right)x
[ Select ]
+V
-V
+M
-M

V=\left(3-\frac{1}{3}x^2\right)kN

\sum M_x=0=(6kNm)-(3kN)(x)+\frac{1}{2}(2/3\,x)x(1/3\,x)
[ Select ]
-Vx
+Vx
+M
-M

M=(-6+3x-\frac{1}{9}x^3) kNm

Choose the missing terms in the above equations
